FLA Series
FLA 24100
2.56kWh
Low Voltage
Up to 15 units
Wall-Mounted or Floor-Mounted
Built-in Wifi
Product Introduction
The battery system main using solar power system for family house.
It also have a with to controller the battery easily and protect our Household application timely.
It also have a with to controller the battery easily and protect our Household application timely.
Product Advantages
● Scalable expansion up to 15 pcs in parallel.
● Built-in WiFi for remote monitor the battery pack data.
● Flexible Installation: wall-mounted or floor-mounted
● LiFePO4: Higher safe performance and longer cycle life
● Multiple Protection with built-in smart BMS, breaker and fuse.
● Compatible with leading inverter brands
● Up to 7-year long warranty.
● FLA24100 Certification：UN38.3
● Built-in WiFi for remote monitor the battery pack data.
● Flexible Installation: wall-mounted or floor-mounted
● LiFePO4: Higher safe performance and longer cycle life
● Multiple Protection with built-in smart BMS, breaker and fuse.
● Compatible with leading inverter brands
● Up to 7-year long warranty.
● FLA24100 Certification：UN38.3
Model
FLA24100
Operating Voltage
22.4-28.8V
Energy
2.56kWh
Scalability
Up to 15 units in parallel(38.4kWh)
Depth of Discharge(DOD)
≥95%
Cycle Life
≥6,000 Cycles
Communication
RS485 / CAN
Protection Level
IP21
Download
- [Certification for Classify of Danger of Batteries] 1124004310-1 (FLA24100)
- [Certification for Safe Transport of Goods] 1124004310-4 (FLA24100)
- [Hazard Information Label] 1124004310-2 (FLA24100)
- [MSDS] 1124004310-3 (FLA24100)
- [UN38.3 TEST REPORT] 1124001110-1 (FLA24100)
- [UN38.3 TEST Summary] 1124001110-2 (FLA24100)
