FLA Series
FLA 48280-EU
15kWh
Low Voltage
Up to 15 units
Movable type Floor-Mounted
Smart BMS
Built-in aerosol fire extinguisher
Built-in WiFi
Starting from: $1925
(Final price depends on order quantity, configuration, and delivery location.
Volume and partner pricing available upon request for qualified partners.)
Product Introduction
FLA48280-EU is equipped with a lithium iron phosphate battery designed for household use. Developed based on customer needs and market demands, this advanced battery storage solution provides high-quality, reliable power for various devices. The product features a long lifespan, suitability for high-temperature environments, and a compact design that requires minimal installation space.
FLA48280-EU features a battery management system independently developed by our team. When connected to a grid or photovoltaic system as the power source, the product can store energy by charging the battery. In the event of a power outage from the grid or photovoltaic system, the product independently supplies electricity to household loads. Additionally, multiple units can be connected in parallel to form a high-capacity, multi-module system, meeting long-term energy storage requirements.
FLA48280-EU features a battery management system independently developed by our team. When connected to a grid or photovoltaic system as the power source, the product can store energy by charging the battery. In the event of a power outage from the grid or photovoltaic system, the product independently supplies electricity to household loads. Additionally, multiple units can be connected in parallel to form a high-capacity, multi-module system, meeting long-term energy storage requirements.
Product Advantages
● LiFePO4: higher safe performance and longer cycle life
● Multiple protection with built-in smart BMS, breaker and fuse.
● Flexible Installation: wall-mounted or floor-mounted
● Compatible with leading inverter brands
● Scalable expansion up to 15 pcs in parallel.
● Built-in WiFi for remote monitor the battery pack data.
● Equipped with an aerosol fire extinguishing system.
● Easily replace the battery fuse when it blows.
● FLA48280-EU Certification：UN38.3、CE-EMC、IEC 62619
● Multiple protection with built-in smart BMS, breaker and fuse.
● Flexible Installation: wall-mounted or floor-mounted
● Compatible with leading inverter brands
● Scalable expansion up to 15 pcs in parallel.
● Built-in WiFi for remote monitor the battery pack data.
● Equipped with an aerosol fire extinguishing system.
● Easily replace the battery fuse when it blows.
● FLA48280-EU Certification：UN38.3、CE-EMC、IEC 62619
Model
FLA48280-EU
Operating Voltage
44.8-57.6V
Energy
15kWh
Scalability
Up to 15 units in parallel(225kWh)
Depth of Discharge(DOD)
≥95%
Cycle Life
≥6,000 Cycles
Communication
RS485 / CAN
Protection Level
IP21
Download
- [Certificate for Safe Transport of Goods by Road] GDFLS2F5301YL501_FLA48280-EU
- [Certificate for Safe Transport of Goods by Sea] GDFLS2F5301YM501_FLA48280-EU
- [Hazard and Classification Identification] GDFLS2F5301DI01_FLA48280-EU
- [Hazard Information Label] GDFLS2F5301P01_FLA48280-EU
- [MSDS] GDFLS2F5301SDS01_[MSDS] FLA48280-EU
- [UN38.3 TEST REPORT] GDFLS2F5301U01_FLA48280-EU
- [UN38.3 TEST Summary] GDFLS2F5301G01_FLA48280-EU
- [Verification of Overcharge-Short-Overdischarge Protection] GDFLS2F5301W01_FLA48280-EU
